P04/3-RS485-CET
Elsner
Description
The P04/3-RS485-CET weather station measures temperature, wind speed, and brightness (east, south, and west sun). It detects precipitation and receives the time signal via GPS. The P04/3-RS485-CET weather station outputs Central European Time (CET), with summer/winter time changes occurring automatically in accordance with the specifications for Central Europe.
The weather station transmits the currently recorded weather data, date, and time once per second.
General Info
| Manufacturer | Type | Protocol | Model | Version | ID |
|---|---|---|---|---|---|
| Elsner | Weather station | SERCOM (DDF) | 2 | 1 | 0x0900004000020100 |
Documents
DDF Items
| ID | Name | Unit | Type | Direction |
|---|---|---|---|---|
| 0 | Temperatur outside | C | ||
| 1 | Sun south | klx | ||
| 2 | Sun west | klx | ||
| 3 | Sun east | klx | ||
| 4 | Twilight Indication | |||
| 5 | Twilight | lx | ||
| 6 | Wind | m/s | ||
| 7 | Raining | |||
| 8 | Time quality | |||
| 9 | Weekday | 1= Mon, 7= Sun, 0 = UTC not OK | ||
| 10 | Year | |||
| 11 | Month | |||
| 12 | Day | |||
| 13 | Hour | |||
| 14 | Minute | |||
| 15 | Seconds | |||
| 16 | Summertime | 1= Summertime, 0= Wintertime, 2 = Not defined | ||
| 17 | Epoch seconds | s | ||
| 18 | Datetime string | |||
| 201 | Quality | |||
| 203 | Error counter | |||
| 204 | Info | |||
| 210 | Sumdata helper | |||
| 211 | Checksum | |||
| 212 | Datalen |
